Mpp Underground Electrical Cable Conduit Pipe Machine Extrusion Machines
The production line is mainly used to produce modified polypropylene cable conduit .Using MPP special screw, the plasticizing effect is better, ensuring the tensile strength of the non-excavated pipe and high-speed production.
Main techinical parameter:
| Model | Extruder | Pipe Range(mm) | Capacity (kg/hr) | Main Motor Power （kw） | Total Power （kw） | Line Length （m） |
| PE-110 | SJ65/33 | 16-110 | 150-200 | 55 | 130 | 28 |
| PE-160 | SJ75/33 | 150-160 | 180-220 | 75 | 150 | 30 |
| PE-250 | SJ75/33 | 75-250 | 280-350 | 90 | 280 | 30 |
MPP Product Size:
| Ordinary Type | Outer Diameter(mm) | Wall Thickness(mm) | Ordinary Length(mm) |
| 110 | 5 | 6,9 or as required | |
| 160 | 8 | 6,9 or as required | |
| 180 | 12 | 6,9 or as required | |
| 200 | 13 | 6,9 or as required | |
| 225 | 15 | 6,9 or as required | |
| 250 | 15 | 6,9 or as required | |
| Enhanced Type | 110 | 7 | 6,9 or as required |
| 160 | 10 | 6,9 or as required | |
| 180 | 15 | 6,9 or as required | |
| 200 | 16 | 6,9 or as required | |
| 225 | 18 | 6,9 or as required | |
| 250 | 18 | 6,9 or as required |
